NBR Rubber Cement Plugs Oil And Gas 1MP-2MP pressure

Brand Name : Puyang Zhongshi Group

Model Number : 4 1/2"~20"

Certification : API,ISO,QHSE

Place of Origin : China

MOQ : 1

Price : Negotiable

Payment Terms : T/T, MoneyGram

Delivery Time : depends on quantity

Packaging Details : Wooden Box

Product : API Conventional Type Top Cementing Rubber Plug

Material : NBR

Type : Convential type

Feature : PDC drillable

Temperature : -30℃ to 150℃

Working Pressure : ≥15MP

Contact Now

API Conventional Type Top Cementing Rubber Plug

A rubber cementing plug used to separate the cement slurry from other fluids, reducing contamination and maintaining predictable slurry performance

API Conventional Type Top Cementing Rubber Features
  • These plugs are completely PDC drillable.

  • Available in 4 1/2" to 20 "sizes + any special sizes.

  • The top plug has a solid body that provides positive indication of contact with the landing collar.

  • Operating range of temperature with Aluminum core is up to 200 degree Fahrenheit

  • Plug can be ordered for higher operating temperature and operation in either synthetic or mud fluids

API Conventional Type Top Cementing Rubber Plug Specification
Casing Casing Weight Range Wiper Fin O.D Working Working Burst Hardness
Size(in) mm in mm in Temperature Pressure Pressure
4 1/2" 14.14-17.26 9.50-11.60 110 4.331 -30℃ to ≥15MP 1MP-2MP 75-95
5" 17.11-35.86 11.50-24.10 122 4.803 150℃
5 1/2" 20.83-39.88 14.00-26.80 135 5.315
7" 25.30-56.55 17.00-38.00 170 6.693
7 5/8" 35.72-63.69 24.00-42.00 185 7.283
9 5/8" 53.57-79.62 36.00-53.50 235 9.252
13 3/8" 71.43-107.15 48.00-72.00 333 13.11 -30℃ to ≥10MP
20" 139.89-197.93 94.00-133.00 498 19.606 150℃

NBR Rubber Cement Plugs Oil And Gas 1MP-2MP pressure
